 TYPE EXPLANATION |
| Linear velocity |
max 1m/s |
| Precision Grade |
min  0.02 |
| Speed |
max 10M/S2 |
| rpm |
max 3000rpm |
| Driving element |
C5 or C7 BallScrew |
| Screw Diameter |
, 15, 16, 20mm |
| Lead |
5, 10, 16, 20mm |
| Travel Range |
Travel Range max 800mm |
|
| Load Capacity |
 |
| Load Capacity (kg) |
Short place SB |
Long place LSB |
| Fx |
40 |
80 |
| Fy |
60 |
100 |
| Fz |
60 |
100 |
| Load Capacity (kg/m) |
| Mx |
5 |
10.2 |
| My |
3 |
11.8 |
| Mz |
3 |
11.6 |
|
| Output pattern |
 |
| AT-88 SERIES (Belt transmission) |
|
| TYPE EXPLANATION |
| Linear velocity |
max 3m/s |
| Precision Grade |
min 0.15 |
| Speed |
max 20M/S2 |
| Driving element |
Gear belt 30AT5 |
| Diameter |
,38.2mm |
| Travel Range |
120mm |
| Travel Range |
Travel Range max 1800mm |
| Load place |
168mm, 220mm or more |
|
| Load Capacity |
 |
| Load Capacity (kg) |
Short place SB |
Long place LSB |
| Fx |
80 |
100 |
| Fy |
100 |
120 |
| Fz |
100 |
120 |
| Load Capacity (kg/m) |
| Mx |
10.2 |
10.2 |
| My |
11.8 |
13.6 |
| Mz |
11.6 |
12.5 |
|
|
|
| TYPE EXPLANATION |
| Linear velocity |
max 1m/s |
| Precision Grade |
min 0.02 |
| Speed |
max 10M/S2 |
| rpm |
max 3000rpm |
| Driving element |
C5 or C7 BallScrew |
| Screw Diameter |
,15, 16mm |
| Lead |
5, 10, 20mm |
| Travel Range |
Travel Range max 800mm |
|
| Load Capacity |
 |
| Load Capacity (kg) |
Short place SB |
Long place LSB |
| Fx |
60 |
100 |
| Fy |
30 |
50 |
| Fz |
45 |
60 |
| Load Capacity (kg/m) |
| Mx |
5.7 |
7.6 |
| Mx |
2.5 |
6.2 |
| Mx |
2.2 |
5.4 |
|
| Output pattern |
 |
| |
|
